14–32
Connector
lock
Bulb
3. Disconnect the wire connector by pushing
and pulling it.
Front fog lights
1. Operate the steering wheel inward
(rightward when replacing the left side;
leftward when replacing the right side).
2. Detach the 3 clips retaining the front fender
liner.
Bulb
with socket
4. Remove the bulb with socket by turning
it counterclockwise about 45 degrees.
Change the bulb with socket.
5. Reverse the removal procedure to
reinstall.
CAUTION
Never touch the glass portion of the bulb.
The oil on your finger will damage it. Be
careful not to pinch the wire connector
when you reinstall.
Sect 14_EN D42L.indd 32 31/10/2019 5:38 PM
