Pharma Test PT-Node - Figure 57: PT-Node Device Settings for PTZ X00; Figure 58: Example of a PTZ 300 Test Report

Pharma Test Apparatebau AG
Operating Manual
B-24-00100_PT-NODE_v1.0e.docx Page 53 of 64
Login to PT-Node as administrator and enter the device menu. Enter the following settings:
Parameter
Setting
Device family
PTZ x00
Listener
Report
File timeout
OFF
Data folder
Enter the desired name for the folder on
the internal storage of PT-Node to save the
results
Figure 57: PT-Node device settings for PTZ x00
Press submit to store the settings.
You can now start measuring with the PTZ instrument. The result report is sent
simultaneously to the internal printer of the device (if present, internal printer optional) and
PT-Node as soon as you select print on the instrument.
Figure 58: Example of a PTZ 300 test report
Refer to the user manual of the instrument for more details about printing and the report
format.
