Login to PT-Node as administrator and enter the device menu. Enter the following settings:
Parameter
Setting
Device family
PTF x00
Listener
Report
File timeout
OFF
Data folder
Enter the desired name for the folder on
the internal storage of PT-Node to save the
results
Figure 60: PT-Node device settings for PTF x00
Press submit to store the settings.
You can now start measuring with the PTF instrument. The result report is sent
simultaneously to the internal printer of the device (if present, internal printer optional) and
PT-Node as soon as you select print on the instrument.
Figure 61: Example of a PTF 100 test report
Refer to the user manual of the instrument for more details about printing and the report
format.
