User’s Manual of GS-5220 LCD Series
106
4.2.3 IP Status
IP Status displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and
the neighbor cache (ARP cache) status. The screen in Figure 4-2-3 appears.
Figure 4-2-3: IP Status Page Screenshot
The page includes the following fields:
Object Description
• IP Interfaces
Interface The name of the interface.
Type
The address type of the entry. This may be LINK or IPv4.
Address The current address of the interface (of the given type).
Status The status flags of the interface (and/or address).
• IP Routes
Network The destination IP network or host address of this route.
