User’s Manual of GS-5220 LCD Series
137
If the destination is running-config, the file will be applied to the switch configuration. This can be done in two
ways:
• Replace mode: The current configuration is fully replaced with the configuration in the uploaded file.
• Merge mode: The uploaded file is merged into running-config.
If the file system is full (i.e. contains the three system files mentioned above plus two other files), it is not
possible to create new files, but an existing file must be overwritten or another deleted first.
4.2.21 Configure Activate
Thje Configure Activate page allows to activate the startup-config and default-config files present on the switch.
Please refer to the Figure 4-2-26 shown below.
Figure 4-2-26: Configuration Activate Page Screenshot
It is possible to activate any of the configuration files present on the switch, except for running-config which
represents the currently active configuration.
Select the file to activate and click
. This will initiate the process of completely replacing
the existing configuration with that of the selected file.
