User’s Manual of GS-5220 LCD Series
258
4.8.2 Profile Table
This page provides IPMC Profile related configurations. The IPMC profile is used to deploy the access
control on IP multicast streams. It is allowed to create at maximum 64 Profiles with at maximum 128
corresponding rules for each. The Profile Table screen in Figure 4-8-5 appears.
Figure 4-8-5: IPMC Profile Configuration Page
The page includes the following fields:
Object Description
• Global Profile Mode
Enable/Disable the Global IPMC Profile.
System starts to do filtering based on profile settings only when the
global profile mode is enabled.
• Delete
Check to delete the entry.
The designated entry will be deleted during the next save.
• Profile Name
The name used for indexing the profile table.
Each entry has the unique name which is composed of at maximum 16
alphabetic and numeric characters. At least one alphabet must be
present.
