User’s Manual of GS-5220 LCD Series
242
4.7.5 MSTI Priorities
This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly
change them as well. The MSTI Priority screen in Figure 4-7-7 appears.
Figure 4-7-7: MSTI Priority Page Screenshot
The page includes the following fields:
Object Description
• MSTI
The bridge instance. The CIST is the default instance, which is always
active.
• Priority
Controls the bridge priority. Lower numerical values have better
priority. The bridge priority plus the MSTI instance number,
concatenated with the 6-byte MAC address of the switch forms a
Bridge Identifier.
