User’s Manual of GS-5220 LCD Series
218
• Adding a New
MAC-based VLAN
Click “Add New Entry” to add a new MAC-based VLAN entry. An empty
row is added to the table, and the MAC-based VLAN entry can be
configured as needed. Any unicast MAC address can be configured for
the MAC-based VLAN entry. No broadcast or multicast MAC addresses
are allowed. Legal values for a VLAN ID are 1 through 4095.
The MAC-based VLAN entry is enabled when you click on "Save". A
MAC-based VLAN without any port members will be deleted when you
click "Save".
The “Delete” button can be used to undo the addition of new
MAC-based VLANs.
Buttons
: Click to add a new MAC-based VLAN entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Click to refresh the page immediately.
: Updates the table starting from the first entry in the MAC-based VLAN Table.
: Updates the table, starting with the entry after the last entry currently displayed.
4.6.9 Protocol-based VLAN
This page allows you to add new protocols to Group Name (unique for each Group) mapping entries as well as
To Next Page
