User’s Manual of GS-5220 LCD Series
383
4.11.4 Network Access Overview
This page provides an overview of the current NAS port states for the selected switch. The Network
Access Overview screen in Figure 4-11-5 appears.
Figure 4-11-5: Network Access Server Switch Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number. Click to navigate to detailed NAS
statistics for this port.
• Admin State
The port's current administrative state. Refer to NAS Admin State
for a description of possible values.
• Port State
The current state of the port. Refer to NAS Port State for a
description of the individual states.
• Last Source
The source MAC address carried in the most recently received
EAPOL frame for EAPOL-based authentication, and the most
recently received frame from a new client for MAC-based
authentication.
