User’s Manual of GS-5220 LCD Series
384
• Last ID
The user name (supplicant identity) carried in the most recently
received Response Identity EAPOL frame for EAPOL-based
authentication, and the source MAC address from the most
recently received frame from a new client for MAC-based
authentication.
• QoS Class
QoS Class assigned to the port by the RADIUS server if enabled.
• Port VLAN ID
The VLAN ID that NAS has put the port in. The field is blank, if the
Port VLAN ID is not overridden by NAS.
If the VLAN ID is assigned by the RADIUS server,
"(RADIUS-assigned)" is appended to the VLAN ID. Read more
about RADIUS-assigned VLANs here.
If the port is moved to the Guest VLAN, "(Guest)" is appended to
the VLAN ID. Read more about Guest VLANs here.
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
4.11.5 Network Access Statistics
This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE 802.1X
authentication. For MAC-based ports, it shows selected backend server (RADIUS Authentication Server)
statistics, only. Use the port select box to select which port details to be displayed. The Network Access
Statistics screen in Figure 4-11-6 appears.
