User’s Manual of GS-5220 LCD Series
385
Figure 4-11-6: Network Access Statistics Page Screenshot
The page includes the following fields:
Port State
Object Description
• Admin State
The port's current administrative state. Refer to NAS Admin State for a
description of possible values.
• Port State
The current state of the port. Refer to NAS Port State for a description
of the individual states.
• QoS Class
The QoS class assigned by the RADIUS server. The field is blank if no
QoS class is assigned.
• Port VLAN ID
The VLAN ID that NAS has put the port in. The field is blank, if the Port
VLAN ID is not overridden by NAS.
If the VLAN ID is assigned by the RADIUS server, "(RADIUS-assigned)" is
appended to the VLAN ID. Read more about RADIUS-assigned VLANs
here.
If the port is moved to the Guest VLAN, "(Guest)" is appended to the
VLAN ID. Read more about Guest VLANs here.
