Planet GS-5220 Series User Manual

User’s Manual of GS-5220 LCD Series
386
Port Counters
Object Description
• EAPOL Counters
These supplicant frame counters are available for the following administrative
states:
■ Force Authorized
■ Force Unauthorized
■ Port-based 802.1X
■ Single 802.1X
■ Multi 802.1X
Direction Name IEEE Name Description
Rx Total dot1xAuthEapolFram
esRx
The number of valid
EAPOL frames of any
type that have been
received by the switch.
Rx Response ID dot1xAuthEapolRespI
dFramesRx
The number of valid
EAPOL Response Identity
frames that have been
received by the switch.
Rx Responses dot1xAuthEapolResp
FramesRx
The number of valid
EAPOL response frames
(other than Response
Identity frames) that
have been received by
the switch.
