User’s Manual of GS-5220 LCD Series
523
4.18.5 RMON History Configuration
Configure RMON History table on this page. The entry index key is ID; screen in Figure 4-18-6 appears.
Figure 4-18-6: RMON History Configuration Page Screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• ID
Indicates the index of the entry. The range is from 1 to 65535.
• Data Source
Indicates the port ID which wants to be monitored.
• Interval
Indicates the interval in seconds for sampling the history statistics data.
The range is from 1 to 3600, default value is 1800 seconds.
• Buckets
Indicates the maximum data entries associated this History control
entry stored in RMON. The range is from 1 to 3600, default value is 50.
• Buckets Granted
The number of data will be saved in the RMON.
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
