User’s Manual of GS-5220 LCD Series
292
4.8.19 MVR SFM Information
Entries in the MVR SFM Information Table are shown on this page. The MVR SFM (Source-Filtered Multicast)
Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by
VLAN ID, then by group, and then by Port. Different source addresses belong to the same group are treated as
single entry.
Each page shows up to 99 entries from the MVR SFM Information Table, default being 20, selected through the
"entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning
of the MVR SFM Information Table.
The "Start from VLAN", and "Group Address" input fields allow the user to select the starting point in the MVR
SFM Information Table. The MVR SFM Information screen in Figure 4-8-22 appears.
Figure 4-8-22: MVR SFM Information Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
VLAN ID of the group.
• Group
Group address of the group displayed.
• Port
Switch port number.
