User’s Manual of GS-5220 LCD Series
311
4.9.10 DSCP Classification
This page allows you to map DSCP value to a QoS Class and DPL value. The DSCP Classification screen in Figure
4-9-11 appears.
Figure 4-9-11: DSCP Classification Page Screenshot
The page includes the following fields:
Object Description
• QoS Class
Available QoS Class value ranges from 0 to 7. QoS Class (0-7) can be
mapped to followed parameters.
• DPL
Actual Drop Precedence Level.
• DSCP
Select DSCP value (0-63) from DSCP menu to map DSCP to
corresponding QoS Class and DPL value
