User’s Manual of GS-5220 LCD Series
271
: Clears all Statistics counters.
Auto-refresh
: Automatic refresh occurs every 3 seconds.
4.8.8 IGMP Group Information
Entries in the IGMP Group Table are shown on this Page. The IGMP Group Table is sorted first by VLAN ID, and
then by group.
Each page shows up to 99 entries from the IGMP Group table, default being 20, selected through the "entries
per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the
IGMP Group Table. The "Start from VLAN", and "group" input fields allow the user to select the starting point in
the IGMP Group Table. The IGMP Groups
Information screen in Figure 4-8-11 appears.
Figure 4-8-9: IGMP Snooping Groups Information Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
VLAN ID of the group.
• Groups
Group address of the group displayed.
