User’s Manual of GS-5220 LCD Series
107
Gateway The gateway address of this route.
Status The status flags of the route.
• Neighbor Cache
IP Address The IP address of the entry.
Link Address
The Link (MAC) address for which a binding to the IP address
given exists.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Click to refresh the page.
4.2.4 Users Configuration
This page provides an overview of the current users. Currently the only way to login as another user on the web
server is to close and reopen the browser. After setup is completed, press the “Apply” button to take effect.
Please login web interface with new user name and password; the screen in Figure 4-2-4 appears.
Figure 4-2-4: Users Configuration Page Screenshot
The page includes the following fields:
Object Description
• User Name
The name identifying the user. This is also a link to Add/Edit User.
