User’s Manual of GS-5220 LCD Series
496
Allocation mode
In this mode, the user allocates the amount of power that each port may reserve. The allocated/reserved
power for each port/PD is specified in the Maximum Power fields. The ports are shut down when total
reserved powered exceeds the amount of power that the power supply can deliver.
In this mode, the port power will not be
turned on if the PD requests more
available power.
LLDP mode
In this mode, the ports of PoE power are managed and determined by LLDP Media Protocol.
4.16.3 Power Over Ethernet Configuration
This section allows the user to inspect and configure the current PoE configuration settings as Figure 4-16-2 appears.
Figure 4-16-2: PoE Configuration Screenshot
