User’s Manual of GS-5220 LCD Series
446
• Max Dynamic Clients
Specify the maximum number of dynamic clients can be learned on
given ports. This value can be 0, 1, 2 and unlimited. If the port mode is
enabled and the value of max dynamic client is equal 0, it means only
allow the IP packets forwarding that are matched in static entries on
the specific port.
Buttons
: Click to translate all dynamic entries to static entries.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.11 IP Source Guard Static Table
This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11
appears.
Figure 4-12-11: Static IP Source Guard Table Screen Page Screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Port
The logical port for the settings.
