User’s Manual of GS-5220 LCD Series
326
4.9.16 Voice VLAN Configuration
The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and
schedule network traffic. It is recommended that there be two VLANs on a port - one for voice, one for data.
Before connecting the IP device to the switch, the IP phone should configure the voice VLAN ID correctly. It
should be configured through its own GUI. The Voice VLAN Configuration screen in Figure 4-9-18 appears.
Figure 4-9-18: Voice VLAN Configuration Page Screenshot
The page includes the following fields:
Object Description
