• Port Description
Indicates the per port description.
• Link
The current link state is displayed graphically. Green indicates the link is
up and red indicates the link is down.
• Current Link Speed
Provides the current link speed of the port.
• Configured Link
Speed
Select any available link speed for the given switch port. Draw the
menu bar to select the mode.
Auto – Set up Auto negotiation for copper interface.
10Mbps HDX - Force sets 10Mbps/Half-Duplex mode.
10Mbps FDX - Force sets 10Mbps/Full-Duplex mode.
100Mbps HDX - Force sets 100Mbps/Half-Duplex mode.
100Mbps FDX - Force sets 100Mbps/Full-Duplex mode.
1Gbps FDX - Force sets 10000Mbps/Full-Duplex mode.
Auto Fiber (10G) – Set up 10G fiber port for negotiation
automatically.
Disable – Shut down the port manually.
• Adv Duplex
When duplex is set as auto i.e auto negotiation, the port will only
advertise the specified duplex as either Fdx or Hdxto the link partner.
By default port will advertise all the supported duplexes if the Duplex is
Auto.
• Adv speed
When Speed is set as auto i.e auto negotiation, the port will only
advertise the specified speeds (10M 100M 1G) to the link partner. By
default port will advertise all the supported speeds if speed is set as
Auto.
