User’s Manual of GS-5220 LCD Series
166
Figure 4-4-3: Detailed Port Statistics Port 1 Page Screenshot
The page includes the following fields:
Receive Total and Transmit Total
Object Description
• Rx and Tx Packets
The number of received and transmitted (good and bad) packets
• Rx and Tx Octets
The number of received and transmitted (good and bad) bytes,
including FCS, but excluding framing bits.
• Rx and Tx Unicast
The number of received and transmitted (good and bad) unicast
packets.
