User’s Manual of GS-5220 LCD Series
222
The page includes the following fields:
Object Description
• Delete
To delete a Group Name to VLAN map entry, check this box. The entry
will be deleted on the switch during the next Save
• Group Name
A valid Group Name is a string of almost 16 characters which consists of
a combination of alphabets (a-z or A-Z) and integers(0-9), no special
character is allowed. Whichever Group name you try map to a VLAN
must be present in Protocol to Group mapping table and must not be
preused by any other existing mapping entry on this page.
• VLAN ID
Indicates the ID to which Group Name will be mapped. A valid VLAN ID
ranges from 1-4095.
• Port Members
A row of check boxes for each port is displayed for each Group Name to
VLAN ID mapping. To include a port in a mapping, check the box. To
remove or exclude the port from the mapping, make sure the box is
unchecked. By default, no ports are members, and all boxes are
unchecked.
• Adding a New Group
to VLAN mapping
entry
Click “Add New Entry” to add a new entry in mapping table. An empty
row is added to the table, the Group Name, VLAN ID and port members
can be configured as needed. Legal values for a VLAN ID are 1 through
4095.
The “Delete” button can be used to undo the addition of new entry.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Click to refresh the page immediately.
