User’s Manual of GS-5220 LCD Series
313
• DMAC
Specify the type of Destination MAC addresses for incoming frame.
Possible values are:
■ Any: All types of Destination MAC addresses are allowed.
■ Unicast: Only Unicast MAC addresses are allowed.
■ Multicast: Only Multicast MAC addresses are allowed.
■ Broadcast: Only Broadcast MAC addresses are allowed.
The default value is 'Any'.
• SMAC
Displays the OUI field of Source MAC address, i.e. first three octet
(byte) of MAC address.
• Tag Type
Indicates tag type. Possible values are:
■ Any: Match tagged and untagged frames.
■ Untagged: Match untagged frames.
■ Tagged: Match tagged frames.
The default value is 'Any'
• VID
Indicates (VLAN ID), either a specific VID or range of VIDs. VID can be in
the range 1-4095 or 'Any'
• PCP
Priority Code Point: Valid value PCP are specific(0, 1, 2, 3, 4, 5, 6, 7) or
range(0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or 'Any'.
• DEI
Drop Eligible Indicator: Valid value of DEI can be any of values between
0, 1 or 'Any'.
