Planet GS-5220 Series User Manual

User’s Manual of GS-5220 LCD Series
317
• LLC
■ SSAP Address Valid SSAP(Source Service Access Point) can vary
from 0x00 to 0xFF or 'Any', the default value is 'Any'
■ DSAP Address Valid DSAP(Destination Service Access Point) can
vary from 0x00 to 0xFF or 'Any', the default value is 'Any'
■ Control Address Valid Control Address can vary from 0x00 to 0xFF
or 'Any', the default value is 'Any'
• SNAP
PID Valid PID(a.k.a Ethernet type) can have value within 0x00-0xFFFF or
'Any', default value is 'Any'
• IPv4
■ Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
■ Source IP Specific Source IP address in value/mask format or
'Any'. IP and Mask are in the format x.y.z.w where x, y, z, and w
are decimal numbers between 0 and 255. When Mask is
converted to a 32-bit binary string and read from left to right, all
bits following the first zero must also be zero
DSCP Diffserv Code Point value(DSCP): It can be specific value,
range of value or 'Any'. DSCP values are in the range 0-63
including BE, CS1-CS7, EF or AF11-AF43
■ IP Fragment IPv4 frame fragmented option: yes|no|any
■ Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port
range applicable for IP protocol UDP/TCP
■ Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or
port range applicable for IP protocol UDP/TCP
