User’s Manual of GS-5220 LCD Series
333
• Action
Indicates the forwarding action of the ACE.
â– Permit: Frames matching the ACE may be forwarded and
learned.
â– Deny: Frames matching the ACE are dropped.
• Rate Limiter
Indicates the rate limiter number of the ACE. The allowed range is 1 to
16. When Disabled is displayed, the rate limiter operation is disabled.
• Port Redirect
Indicates the port redirect operation of the ACE. Frames matching the
ACE are redirected to the port number.
The allowed values are Disabled or a specific port number. When
Disabled is displayed, the port redirect operation is disabled.
• Mirror
Specify the mirror operation of this port. The allowed values are:
â– Enabled: Frames received on the port are mirrored.
â– Disabled: Frames received on the port are not mirrored.
The default value is "Disabled".
• CPU
Forward packet that matched the specific ACE to CPU.
• CPU Once
Forward first packet that matched the specific ACE to CPU.
• Counter
The counter indicates the number of times the ACE was hit by a frame.
• Conflict
Indicates the hardware status of the specific ACE. The specific ACE is
not applied to the hardware due to hardware limitations.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Click to refresh the page.
