User’s Manual of GS-5220 LCD Series
354
• TCP URG
Specify the TCP "Urgent Pointer field significant" (URG) value for this
ACE.
■ 0: TCP frames where the URG field is set must not be able to
match this entry.
■ 1: TCP frames where the URG field is set must be able to match
this entry.
■ Any: Any value is allowed ("don't-care").
 Ethernet Type Parameters
The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected.
Object Description
• EtherType Filter
Specify the Ethernet type filter for this ACE.
■ Any: No EtherType filter is specified (EtherType filter status
is "don't-care").
■ Specific: If you want to filter a specific EtherType filter with
this ACE, you can enter a specific EtherType value. A field for
entering a EtherType value appears.
• Ethernet Type Value
When "Specific" is selected for the EtherType filter, you can enter a
specific EtherType value.
The allowed range is 0x600 to 0xFFFF but excluding 0x800(IPv4),
0x806(ARP) and 0x86DD(IPv6). A frame that hits this ACE matches this
EtherType value.
Buttons
