User’s Manual of GS-5220 LCD Series
39
Operating
Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage
Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Product
GS-5220-24UP4XV GS-5220-24UP4XVR GS-5220-
24UPL4XV
GS-5220-24UPL4XVR
Hardware Specifications
Copper Ports 24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP+ Slots
4 10GBASE-SR/LR SFP+ interfaces (Port-25 to Port-28)
Compatible with 1000BASE-SX/LX/BX SFP transceiver
Console 1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 128Gbps/non-blocking
Throughput 95.23Mpps@64Bytes
Address Table 16K entries, automatic source address learning and aging
Shared Data Buffer 32M bits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame 10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
Dimensions (W x D x H) 440 x 300 x 56 mm, 1.25U height
Weight 4635g 4675g 5339g 5439g
Power Consumption
Max. 488
watts/1665.13
BTU
AC: Max. 488
watts/1665.13
BTU
DC: Max. 36.6
watts/124.88 BTU
Max. 723
watts/2466.98
BTU
AC: Max. 723
watts/2466.98
BTU
DC: Max. 36.6
watts/124.88 BTU
Power Requirements – AC AC 100~240V, 50/60Hz, 7A
Power Requirements – DC -- DC 36~60V, 2A -- DC 36~60V, 2A
ESD Protection 6KV DC
Fan 3 smart fans
