User’s Manual of GS-5220 LCD Series
428
• State
This column shows the current state of the port as seen from the Limit
Control's point of view. The state takes one of four values:
Disabled: Limit Control is either globally disabled or disabled on the
port.
Ready: The limit is not yet reached. This can be shown for all
actions.
Limit Reached: Indicates that the limit is reached on this port. This
state can only be shown if Action is set to None or Trap.
Shutdown: Indicates that the port is shut down by the Limit Control
module. This state can only be shown if Action is set to Shutdown
or Trap & Shutdown.
• Re-open Button
If a port is shutdown by this module, you may reopen it by clicking this
button, which will only be enabled if this is the case. For other
methods, refer to Shutdown in the Action section.
Note, that clicking the reopen button causes the page to be refreshed,
so non-committed changes will be lost.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to refresh the page. Note that non-committed changes will be lost.
