User’s Manual of GS-5220 LCD Series
452
The "Start from port address", "VLAN", "MAC address" and "IP address" input fields allow the user to select the
starting point in the Dynamic ARP Inspection Table. Clicking the “Refresh” button will update the displayed table
starting from that or the closest next Dynamic ARP Inspection Table match. In addition, the two input fields will -
upon a “Refresh” button click - assume the value of the first displayed entry, allowing for continuous refresh
with the same start address.
The “>>” will use the last entry of the currently displayed as a basis for the next lookup. When the end is reached
the text "No more entries" is shown in the displayed table. Use the “|<<” button to start over. The page includes
the following fields:
Object Description
• Port
The port number for which the status applies. Click the port number to
see the status for this particular port.
• VLAN ID
The VLAN ID of the entry.
• MAC Address
The MAC address of the entry.
• IP Address
The IP address of the entry.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input
fields.
: Flushes all dynamic entries.
: Updates the table starting from the first entry in the MAC Table, i.e. the entry with the lowest VLAN
ID and MAC address.
: Updates the table, starting with the entry after the last entry currently displayed.
