User’s Manual of GS-5220 LCD Series
457
The “>>” will use the last entry of the currently displayed VLAN/MAC address pairs as a basis for the next
lookup. When the end is reached the text "no more entries" is shown in the displayed table. Use the “|<<”
button to start over.
The page includes the following fields:
Object Description
• Type
Indicates whether the entry is a static or dynamic entry.
• VLAN
The VLAN ID of the entry.
• MAC Address
The MAC address of the entry.
• Port Members
The ports that are members of the entry.
Buttons
Auto-refresh
: Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input
fields.
: Flushes all dynamic entries.
: Updates the table starting from the first entry in the MAC Table, i.e. the entry with the lowest VLAN
ID and MAC address.
: Updates the table, starting with the entry after the last entry currently displayed.
