User’s Manual of GS-5220 LCD Series
504
• Current Budget
Displays the current maximum PoE budget.
• Current Ports in Use
Displays the current PoE ports in use.
• Class 1 ~ 4 ports
Displays the current PoE class 1 ~ 4 ports.
• Power Consumption
Displays the current power consumption (total watts and percentage)
• Reserved Power
(Reserved mode)
Shows how much the total power is reserved for all PDs.
• PoE Temperature
Displays the current operating temperature of the first PoE chip unit.
• Current Power
Consumption
Shows the total watts usage of Managed PoE Switch.
• Total Power Reserved
Shows how much the total power is reserved for all PDs.
• Temperature 1/2/3/4
Displays the current operating temperature of the first PoE chip unit.
• Local Port
This is the logical port number for this row.
• PD Class
Displays the class of the PD attached to the port, as established by the
classification process. Class 0 is the default for PDs. The PD is powered
based on PoE Class level if system is working in Classification mode. A PD
will return Class to 0 to 4 in accordance with the maximum power drawn
as specified by Table 4-16-1.
• Power Used [W]
The Power Used shows how much power the PD currently is using.
• Current Used [mA]
The Power Used shows how much current the PD currently is using.
• Priority
The Priority shows the port's priority configured by the user.
• Port Status
The Port Status shows the port's status.
• Power Inline Mode
Displays per PoE port operating in mid-span, end-span or UPoE mode.
• Total
Shows the total power and current usage of all PDs.
