4.3.6.2 IGMP Profile
This option allows you to configure the IGMP ACL (Access Control List) profile. This
profile defines the IGMP multicast channels, which are allowed to join for each ADSL port.
That is, a multicast stream will be copied to an ADSL port only if that multicast stream is
registered in the ACL profile that is bound to this ADSL port. The maximum number of
IGMP multicast channels in an ACL profile is 256. Note that the same multicast channel
can be existed concurrently in two or more ACL profiles.
The ACL profile will be referred to only when ACL mode is enabled in the IGMP
Configuration page (refer to section 4.3.6). From the Bridge menu, click on IGMP and
then IGMP Profile. The following page is displayed:
IGMP Profile page = >
IGMP ACL Profile Configuration
Label Descri
tion
Profile ID Click on this drop-down list and specify the profile ID. Valid value is 01 ~ 48.
IP CHANNEL MAP
Click on this drop-down list and select the channel index range.
Options are: Channel 001~032, Channel 033~064, …, Channel 225~256.
All select
Click on this checkbox to select all channels in this page at one time. This is
convenient for quick value assignment.
- 133 -
