Quickly IP Assign
Type the IGMP group IP address here for quick assignment. Click on Assign
button to put the value into the table. Then you can modify parts of the IP
addresses directly in the table.
Quickly VID Assign
Type the IGMP group IP address here for quick assignment. Click on Assign
button to put the value into the table.
Assign
Click on this button to apply the parameter values you have just entered. But
these values haven’t been really saved in the database. You must click on
Create to save the values. Once the setting has been saved, you cannot
modify the values. You must delete the channel and then create again.
Select
Click on this checkbox to select the channel you want to create, delete, or
assign values.
IP Address
You can type the IGMP group address here and then click on Create button
to save. Valid values: 224.0.0.0 ~ 239.255.255.255. The range of addresses
from 224.0.0.0 to 224.0.0.255 is reserved for the use of routing protocols
and other low-level topology discovery or maintenance protocols.
Query Click on this button to display current channels in the profile.
Create Click on this button to create new channels (IGMP group address).
Delete Click on this button to delete channel(s) (IGMP group address).
Binding Profile page = >
IGMP ACL Profile Binding
Label Descri
tion
Click on these drop-down lists to select a line bridge port.
- 134 -
