All select
Click on this checkbox to select all ports in this page at one time.
This is convenient for quickly value assignment.
Quickly Max Group Assign
This field is for quick value assignment (assign the same value to
all the ports in current page at one time). Type in the maximum
IGMP groups can be joined simultaneously per line port, and then
click on Assign to put the value into the table.
Quickly Profile ID Assign
Click on this drop-down list to select the profile ID you want to
bind. This is for quick value assignment.
Quickly Binding Assign
Click on this drop-down list to select the binding action. This is for
quick value assignment.
Options are: off -- unbind the profile, on -- bind the profile, reset --
rebind the profile.
Assign
Click on this button to apply the parameter values you have just
entered (or selected). But these values haven’t been really saved
in the database. You must click on Modify to save the values.
Modify Click on this button to submit the modification.
Port
Click on the checkbox to select the port you want to modify or
assign values.
Max Groups
You can type in the maximum IGMP groups can be joined
simultaneously to limit the concurrent multicast channels for a
bridge port. This value is effective only when the limit maximum
IGMP groups function is enabled (refer to section 4.3.6).
Profile ID You can select the profile ID you want to bind here.
Binding Status You can select the binding action here.
- 135 -
