4.4.1.3 Spectrum Main Profile
This option allows you to configure the ADSL spectrum profile. From the ADSL menu,
click on Profile and then Spectrum Profile(main). The following page is displayed.
ADSL Spectrum Profile setup
Label Descri
tion
Select Index
Click on the drop-down list and select the range of profile index.
Options are: 1~4, 5~8, …, 117~120.
Index
This field shows the profile index. Click on the radio button beside the profile index
to select the profile you want to modify or delete.
Note that profile 1 (default) cannot be modified or deleted.
Name Type in the name of the profile.
Power Mode
Click on the radio button to select allowed power management mode. Options are
Disable (only L0 state allowed), L2 (L0 and L2 states allowed), L2L3 (L0, L2, and L3
states allowed).
L0 Time
Type in the minimum time (in seconds) between Exit from L2 low power state and
the next Entry into the L2 low power state. Value range is 0 ~ 255.
L2 Time
Type in the minimum time (in seconds) between an Entry into L2 low power state
and the first L2 low power trim request, and between two consecutive L2 power trim
requests. Value range is 0 ~ 255.
L2 ATPR
Type in the maximum aggregate transmit power reduction (in dB) that is allowed at
- 145 -
