Planmeca Intra X-ray unit 27
OTHER INSTALLATION ALTERNATIVES
Installation manual
Shorten the ceiling arm if needed and attach the mounting rings to the arm. Do not tighten the
screws yet.
NOTE If the optional adapter cover is used, attach it to its position before attach-
ing the ceiling arm.
Ceiling arm
Mounting rings
Note, that the attachment screws of the upper
mounting ring must be on the lower edge of the ring,
and the screws of the lower ring on the upper edge.
Adapter cover
Ceiling arm

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
