Planmeca Intra X-ray unit 47
ATTACHING THE GENERATOR BOX WITHOUT THE ADAPTER PLATE
Installation manual
Secure the cover into position with the three M4x6 ULS screws.
Connect the control panel cable to its terminal at the underside of the generator box.
I_15APSU2.eps
M4x6 ULS
