10 Help messages
The X-ray unit incorporates a self-checking feature that monitors the
operation of the unit. If the system detects an operating error, a help
message (e.g. H101) appears on the touch screen.
The X-ray unit will not accept any commands from the user until the help
message is cleared from the touch screen. Clear the message by touching
the green check mark.
The following list shows, in numerical order, all the help messages that can
appear.
Code Explanation Comments
H101 Exposure
switch
The exposure button was
released before end of exposure.
Guide the patient away from the
X-ray unit before moving the C-
arm.
Press and hold down the
exposure button for the entire
duration of the exposure.
H102 The exposure button is stuck or
the cable is short circuited.
Release the exposure button.
If necessary, contact your service
technician to replace the
exposure switch.
H103 ProTouch
desktop
application
The ProTouch desktop
application needs to be closed.
Restart the application.
H105 Emergency
stop button
The emergency stop button has
been activated.
All movements of the X-ray unit
are blocked, no radiation is
generated.
Guide the patient away from the
X-ray unit. Then release the
emergency stop button to resume
normal operation.
H112 Collimator Check panoramic X-collimator
position setting.
Check the collimator settings.
H113 Check panoramic X-collimator
width setting.
Check the collimator settings.
H114 DEC DEC calibration initialization
failed.
Check the sensor connection.
H115 DEC is receiving too much
radiation.
Change the exposure values.
H116 DEC is receiving too little
radiation.
Change the exposure values.
H127 Cephalometric DEC exposure too
long.
H130 Patient safety
area
Patient safety area violation
detected.
Check the scan and layer
settings.
H131 Tomography Patient safety area violation in
tomo slice 1.
Check the slice count and / or
step between slices.
H132 Patient safety area violation in
tomo slice 2.
Check the slice count and / or
step between slices.
10 Help messages
User's manual Planmeca ProMax 99
