NOTE
If you use the chin support, position the patient so that the chin touches the
top bar as shown.
NOTE
If you use the chin support or the chin cup, use for example a cotton roll to
ensure that the patient’s upper and lower incisors do not overlap.
The positioning lights show on the patient’s face.
1. Frankfort plane light 2. Midsagittal plane light 3. Layer light
6 Panoramic exposure
44 Planmeca ProMax User's manual
