SCHEMATIC CABLE/WIRE TERMINATION TABLE
INDEX CCT # TYPE GAUGE COLOR FROM COMPONENT FROM PORT TO COMPONENT TO PORT FUNCTION
1 BUSA_3_5 BUS BUS BUS LOAD CENTER A3 LOAD CENTER A5 CHASSIS LOAD CENTER BUS
2 BUSA_5_7 BUS BUS BUS LOAD CENTER A5 LOAD CENTER A7 CHASSIS LOAD CENTER BUS
3 BUSB_5_7 BUS BUS BUS LOAD CENTER B5 LOAD CENTER B7 EV LEARN LOAD CENTER BUS
4 BUSB_7_9 BUS BUS BUS LOAD CENTER B7 LOAD CENTER B9 EV LEARN LOAD CENTER BUS
5 EA05 TXL 0.5 RD ECU_CNA 5 SPLICE,CRITICAL POWER #1 2 CRITICAL PWR
6 EA06 TXL 0.5 RD SPLICE,CRITICAL POWER #1 2 ECU_CNA 6 CRITICAL PWR
7 EA13 TXL 0.5 OG/BK ECU_CNA 13 BRAKE SWITCH SPLICE 2 BRAKE SW
8 EA32-3 TXL 0.5 OG/WH GROUND SPEED SENSOR A GROUND SPEED CAPACITOR P1 SPEED SENSOR PWR
9 PCR01 TXL 2.0 RD PBR (DC POWER) P3 SPLICE,CRITICAL POWER #1 1 CRITICAL PWR
10 PCR02 TXL 1.0 RD SPLICE,CRITICAL POWER #1 2 SPLICE,CRITICAL POWER #2 1 CRITICAL PWR
11 PCR03 TXL 0.8 RD SPLICE,CRITICAL POWER #1 1 LOAD CENTER C8 CRITICAL PWR
12 PCR03-1 TXL 0.5 RD LOAD CENTER C8 LOAD CENTER D8 CRITICAL PWR
13 PCR03-2 TXL 0.5 RD LOAD CENTER D4 LOAD CENTER D8 CRITICAL PWR
14 PCR04 TXL 0.5 RD/BK LOAD CENTER B6 VCM 1 VCM CRITICAL PWR
15 PCR05 TXL 1.0 RD SPLICE,CRITICAL POWER #1 2 DIAGNOSTIC POWER B CRITICAL PWR
16 PCR07 TXL 0.8 RD OIL PUMP A SPLICE,CRITICAL POWER #2 2 CRITICAL PWR
17 PCR08 TXL 0.8 RD FUEL PUMP 1 SPLICE,CRITICAL POWER #2 2 CRITICAL PWR
18 PCR10 TXL 0.8 RD/BK LOAD CENTER D9 LOAD CENTER B9 BRAKE LIGHT PWR
19 PCR11 TXL 0.8 RD/BK HANDLEBAR CONNECTION 3 LOAD CENTER B8 FUSED BRAKE LIGHT PWR
20 PCR14 TXL 0.8 RD/BK LOAD CENTER C3 LOAD CENTER B4 FUSED GAUGE PWR
21 PCR15 TXL 0.8 RD/BK SPLICE,LIGHT POWER 1 LOAD CENTER B4 FUSED LIGHT PWR
22 PCR15-1 TXL 0.8 RD/BK SPLICE,LIGHT POWER 2 HOOD/CHASSIS 1 LOW BEAM PWR
23 PCR15-2 TXL 0.8 RD/BK SPLICE,LIGHT POWER 2 REAR HARNESS A TAIL LIGHT PWR
24 PCR15-3 TXL 0.5 RD/BK SPLICE,LIGHT POWER 2 LEFT HAND CONTROLS 1 CRITICAL PWR
25 PCR19 TXL 0.8 OG/BK HANDLEBAR CONNECTION 4 BRAKE SWITCH SPLICE 1 BRAKE SIGNAL
26 PCR19-1 TXL 0.8 OG/BK BRAKE SWITCH SPLICE 1 REAR HARNESS B BRAKE SIGNAL
27 PCR19-2 TXL 0.5 OG/BK BRAKE SWITCH SPLICE 2 VCM 5 BRAKE SIGNAL
28 PCR20 TXL 0.8 YE/RD HOOD/CHASSIS 7 LEFT HAND CONTROLS 4 HIGH BEAM HEADLIGHT PWR
29 PCR21 TXL 0.8 RD/BK LOAD CENTER D9 DIAGNOSTIC POWER C GAUGE TEST PWR
09/25/20
1
2
3
A
B
C
D
E
F
G
H
I
4
5
6
789
10
WIRE COLOR LEGEND
BG
BK
BU
DB
BN
GY
GN
DG
OG
PK
RD
VT
WH
YE
BEIGE (TAN)
BLACK
LIGHT BLUE
DARK BLUE
BROWN
GRAY
LIGHT GREEN
DARK GREEN
ORANGE
PINK
RED
VIOLET (PURPLE)
WHITE
YELLOW
TWO WIRE COLORS ARE SHOWN
WITH MAIN/TRACE COLORS.
EXAMPLE:RD/YE = RED WITH
YELLOW TRACE.
CRITICAL POWER CIRCUIT
E = ENGINE GROUND
C = CHASSIS GROUND
NC = SWITCH NORMALLY CLOSED
NO = SWITCH NORMALLY OPEN
HARNESS: 2415122_650_850_CRIT-01
SHEET NO. 2 OF 2
DRAWN: 30-APR-20
CL CLEAR
