Polycom CX5100 Administrator's Guide

Configuration Parameters
Polycom, Inc. 58
<httpd/>
The system contains a local Web Configuration Utility server for user and administrator features. Note that
several of these parameters can be used with Microsoft Skype for Business Server and have two default
states: a generic default value and a different value when the system is registered with Skype for Business
Server. The following table lists the default values for both states where applicable.
The web server supports both basic and digest authentication. The authentication user name and password
are not configurable for this release.
DNS-SRV Parameters
Parameter Permitted values Default
dns.cache.SRV.x.name domain name string with SRV prefix Null
The domain name string with SRV prefix.
dns.cache.SRV.x.port 0 to 65535 0
The port on this target host of this service. For more information, see RFC 2782.
dns.cache.SRV.x.priority 0 to 65535 0
The priority of this target host. For more information, see RFC 2782.
dns.cache.SRV.x.target domain name string Null
The domain name of the target host. For more information, see RFC 2782.
dns.cache.SRV.x.ttl 300 to 536870912 (2^29), seconds 300
The TTL describes the time period the system uses the configured static cache record. If a dynamic network request
receives no response, this timer begins on first access of the static record and once the timer expires, the next
lookup for that record retries a dynamic network request before falling back on the static entry and its reset TTL timer
again.
dns.cache.SRV.x.weight 0 to 65535 0
A server selection mechanism. For more information, see RFC 2782.
HTTPD (Web Server) Parameters
Parameter Permitted Values Default
httpd.enabled
1
0 or 1 Generic=1
Lync=0
If 0, the HTTP server is disabled (the Web Configuration Utility is also be disabled). If 1, the server is enabled.
httpd.cfg.enabled
1
0 or 1 Generic=1
Lync=0
If 0, the Web Configuration Utility is disabled. If 1, the Web Configuration Utility is enabled.

Polycom CX5100 Specifications

General

Product type	Group video conferencing system
Product color	Black
Number of persons	- person(s)
Megapixel	2 MP
Sensor type	-
Image sensor size	- \
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 640 x 480 (VGA), 1056 x 144, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Frequency range	160 - 22000 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	15 - 85 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	110 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	325 mm
Width	369 mm
Height	348 mm
Weight	2300 g
Package depth	430 mm
Package width	520 mm
Package weight	9070 g
