Polycom CX5100 Administrator's Guide

Configuration Parameters
Polycom, Inc. 65
<qos/>
These parameters listed in the next table configure the following Quality of Service (QoS) options:
● The 802.1p/Q user_priority field RTP, call control, and other packets
● The “type of service” field RTP and call control packets
If 1, a user must log in when the login feature is enabled. If 0, the user does not have to log in.
prov.loginCredPwdFlushed.enabled 0 or 1 1
If 1, when a user logs in or logs out, the login credential password is reset. If 0, the login credential password is not
reset.
prov.polling.enabled 0 or 1 0
If 0, the provisioning server is not automatically polled for upgrades. If 1, the provisioning server is polled.
prov.polling.mode abs, rel, random abs
The polling mode.
abs The system polls every day at the time specified by prov.polling.time.
rel The system polls after the number of seconds specified by prov.polling.period.
random The system polls at random between a starting time set in prov.polling.time and an end time set in
prov.polling.timeRandomEnd.
Note that if you set the polling period in prov.polling.period to a time greater than 86400 seconds (one day)
polling occurs on a random day within that polling period (meaning values such as 86401 would be over 2 days) and
only between the start and end times. The day within the period is decided based upon the systems MAC address
and does not change with a reboot whereas the time within the start and end is calculated again with every reboot.
prov.polling.period integer > 3600 86400
The polling period in seconds. The polling period is rounded up to the nearest number of days in absolute and
random mode. In relative mode, the polling period starts once the system boots. In random mode, if this is set to a
time greater than 86400 (one day) polling occurs on a random day based on the system’s MAC address.
prov.polling.time hh:mm 03:00
The polling start time. Used in absolute and random modes.
prov.polling.timeRandomEnd hh:mm Null
The polling stop time. Only used in random mode.
prov.quickSetup.enabled 0 or 1 0
If 0, the quick setup feature is disabled. If 1, the quick setup feature is enabled.
1
Change causes system to restart or reboot.
Provisioning Parameters (continued)
Parameter Permitted Values Default

Polycom CX5100 Specifications

General

Product type	Group video conferencing system
Product color	Black
Number of persons	- person(s)
Megapixel	2 MP
Sensor type	-
Image sensor size	- \
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 640 x 480 (VGA), 1056 x 144, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Frequency range	160 - 22000 Hz
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	15 - 85 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	110 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	325 mm
Width	369 mm
Height	348 mm
Weight	2300 g
Package depth	430 mm
Package width	520 mm
Package weight	9070 g
