(Adapted by Atlantic Broadband)
VVX Color Expansion Module Hardware Feature Descriptions
Reference
Number
Feature
Feature Description
1 Line Key Selects available line key contacts, functions, and assignments.
2 LED Indicators Indicates a line or busy lamp field contact's status. The following lists the LED
Indicator behaviors shown on the expansion modules:
●
Solid Green Indicates an active call in progress.
●
Fast-Flashing Green Indicates an incoming call.
●
Flashing Green Indicates the remote party placed the call on hold
●
Solid Red Indicates the phone of a monitored busy lamp field
contact is placing a call or is in a call.
●
Flashing Red Indicates a held call.
●
Flashing Green and Red Indicates the phone of a monitored busy
lamp field contact is on an active call or is receiving an incoming call.
3 Page Keys Navigates between pages on the expansion module.
4 Base Stand Hooks into the back of the expansion module to stand up the display.
5 LED Page
Indicators
Indicates a page's status.
• Fast-Flashing Green Indicates an incoming call on a page not currently
displayed. Press the page key with the fast-flashing green LED indicator to view
the contact with an incoming call.
• Slow-Flashing Green Indicates a monitored busy lamp field contact on a page
not currently displayed is receiving an incoming call.
• Solid Red Indicates the current page displayed.
6 Color Display Displays line numbers, busy lamp field contacts, and favorites.
.
