(Adapted by Atlantic Broadband)
Overview of Polycom VVX Business Media Phones
VVX 500 and VVX 600 Hardware
The following figure displays the hardware features on the VVX 500 and 600 business media
phones. The
table lists each numbered feature shown in this figure.
Figure 4: VVX 500 and VVX 600 hardware features
VVX 500 and 600 Hardware Feature Descriptions
Reference
Number
Feature Feature Description
1 Reversible tab Secures the handset in the cradle when your phone stand is positioned at a
high angle. To secure the handset, remove the tab, reverse it so the
protrusion points up, and re-insert it. Position the handset so the protrusion
on the tab fits into the slot on the handset.
2 Speaker Provides ringer and speakerphone audio output.
3 Dialpad keys Enable you to enter numbers, letters, and special characters. You can also
use the dialpad keys to select menu items that have index numbers.
4 Security slot (on
side)
Enables you to attach a universal security cable lock to your phone so you
can secure it to a desktop.
5 Microphone Transmits audio to other phones.
6 Volume keys Adjust the volume of the handset, headset, speaker, and ringer.
7 Mute key Mutes local audio during calls and conferences. The key glows red when
activated.
8 Speakerphone key Enables you to place and receive calls using the speakerphone. The key
glows green when activated.
