PA1621 Maintenance Manual All Series | January 2017
4 Shock Absorber Pin Nut
6
99-121 lb-ft (134-164 Nm)
5 Shock Absorber Pin
6
350-400 lb-ft (475-542 Nm)
6 Drive axle Radius Rod Nut/bolt
6
225-255 lb-ft (305-346 Nm)
7 Drive Axle Longitudinal Radius Rod Retaining Bolt
2
185-227 lb-ft (251-308 Nm)
8 Tag Axle Radius Rod Nut
6
228-252 lb-ft (309-342 Nm)
9 Sway Bar Bushing Collar Bolt
8
80-100 lb-ft (108-136 Nm)
10 Tag Axle Transversal Radius Rod (Casting) Retaining
Bolt
1 185-227 lb-ft (251-308 Nm)
11 Sway Bar Link Pin Stud
4
350-400 lb-ft (475-542 Nm)
12 Shock Absorber Lower Nut
6
60-75 lb-ft (81-102 Nm)
13 Tag Axle Radius Rod Nut
6
158-193 lb-ft (214-262 Nm)
14 Tag Axle Radius Rod Stud
6
90-110 lb-ft (122-149 Nm)
Apply corrosion-protective compound on exposed threads.
