DDEC V Code PID SID FMI DESCRIPTION
26 -- 25 11 Aux. Shutdown #1 Active
26 -- 61 11 Aux. Shutdown #2 Active
27 105 -- 3
Intake Manifold Temperature Sensor Input Voltage
High
27 171 -- 3 Ambient Air Temperature Sensor Input Voltage High
27 172 -- 3 Air Temperature Sensor Input Voltage High
28 105 -- 4
Intake Manifold Temperature Sensor Input Voltage
Low
28 171 -- 4 Ambient Air Temperature Sensor Input Voltage Low
28 172 -- 4 Air Temperature Sensor Input Voltage Low
29 351 — 4 TCI Temperature Circuit Failed Low
29 404 — 4
Turbo Compressor Temperature Out Sensor Input
Voltage Low
31 -- 51 3 Aux. Output #3 Open Circuit (High Side) – Pin E-49
31 -- 51 4 Aux. Output #3 Short To Ground (High Side) – Pin E-49
31 -- 51 7 Aux. Output #3 Mechanical System Fail - Pin E-49
31 -- 52 3 Aux. Output #4 Open Circuit (High Side) - Pin E-48
31 -- 52 4 Aux. Output #4 Short to Ground (High Side) - Pin E-48
31 -- 52 7 Aux. Output #4 Mechanical System Failure - Pin E-48
31 -- 260 3 Aux. Output #12 Open Circuit (High Side) - Pin E-46
31 -- 260 4 Aux. Output #12 Short to Ground (High Side) - Pin E-46
31 -- 260 7 Aux. Output #12 Mechanical System Failure - Pin E-46
31 -- 261 3 Aux. Output #13 Open Circuit (High Side) - Pin E-47
31 -- 261 4 Aux. Output #13 Short to Ground (High Side) - Pin E-47
31 -- 261 7 Aux. Output #13 Mechanical System Failure - Pin E-47
31 -- 262 3 Aux. Output #14 Open Circuit (High Side) - Pin E-50
31 -- 262 4 Aux. Output #14 Short to Ground (High Side) - Pin E-50
31 -- 262 7 Aux. Output #14 Mechanical System Failure - Pin E-50
31 -- 263 3 Aux. Output #15 Open Circuit (High Side) - Pin E-51
31 -- 263 4 Aux. Output #15 Short to Ground (High Side) - Pin E-51
31 -- 263 7 Aux. Output #15 Mechanical System Failure - Pin E-51
31 -- 264 3 Aux. Output #16 Open Circuit (High Side) - Pin E-52
31 -- 264 4 Aux. Output #16 Short to Ground (High Side) - Pin E-52
31 -- 264 7 Aux. Output #16 Mechanical System Failure - Pin E-52
31 -- 265 3 Aux. Output #17 Open Circuit (High Side) - Pin E-53
31 -- 265 4 Aux. Output #17 Short to Ground (High Side) - Pin E-53
31 -- 265 7 Aux. Output #17 Mechanical System Failure - Pin E-53
32 -- 238 3 RSL Short to Battery (+)
