Technical Information
125
DDEC V Code PID SID FMI DESCRIPTION
58 92 -- 0 Torque Overload
61 -- xxx 0 Injector xxx Response Time Long
62 -- 26 3 Aux. Output #1 Short to Battery (+) – Pin V-4
62 -- 26 4 Aux. Output #1 Open Circuit - Pin V-4
62 — 26 7
Aux. Output #1 Mechanical System Not Responding
Properly - Pin V-4
62 -- 40 3 Aux. Output #2 Short to Battery (+) - Pin V-5
62 -- 40 4 Aux. Output #2 Open Circuit - Pin V-5
62 — 40 7
Aux. Output #2 Mechanical System Not Responding
Properly – Pin V-5
62 -- 53 3 Aux. Output #5 Short to Battery (+) - Pin V-6
62 -- 53 4 Aux. Output #5 Open Circuit - Pin V-6
62 — 53 7
Aux. Output #5 Mechanical System Not Responding
Properly - Pin V-6
62 -- 54 3 Aux. Output #6 Short to Battery (+) - Pin V-7
62 -- 54 4 Aux. Output #6 Open Circuit - Pin V-7
62 -- 54 7
Aux. Output #6 Mechanical System Not Responding
Properly - Pin V-7
62 -- 55 3 Aux. Output #7 Short to Battery (+) - Pin V-40
62 -- 55 4 Aux. Output #7 Open Circuit - Pin V-40
62 — 55 7
Aux. Output #7 Mechanical System Not Responding
Properly - Pin V-40
62 -- 56 3 Aux. Output #8 Short to Battery (+) – Pin V-53
62 -- 56 4 Aux. Output #8 Open Circuit - Pin V-53
62 -- 56 7
Aux. Output #8 Mechanical System Not Responding
Properly - Pin V-53
62 -- 257 3 Aux. Output #9 Open Circuit – Pin V-54
62 -- 257 4 Aux. Output #9 Short to Gnd – Pin V-54
62 -- 257 7 Aux. Output #9 Mechanical System Failure – Pin V-54
62 -- 258 3 Aux. Output #10 Open Circuit – Pin V-55
62 -- 258 4 Aux. Output #10 Short to Gnd – Pin V-55
62 -- 258 7 Aux. Output #10 Mechanical System Failure – Pin V-55
62 -- 259 3 Aux. Output #11 Open Circuit – Pin E-13
62 -- 259 4 Aux. Output #11 Short to Gnd – Pin E-13
62 -- 259 7 Aux. Output #11 Mechanical System Failure – Pin E-13
63 -- 57 0 PWM #1 Above Normal Range, Pin V-53
63 -- 57 1 PWM #1 Below Normal Range, Pin V-53
63 -- 57 3 PWM #1 Short to Battery (+), Pin V-53
63 -- 57 4 PWM #1 Open Circuit, Pin V-53
