LED states Description
On The indication is steadily lit up.
Off The indication is not lit up.
Flashing The indication is turned on or off in phases, with a frequency of 2.5 Hz:
On for 200 ms, followed by off for 200 ms.
Simple flash The indication shows a short flash (200 ms), followed by a long off phase (1 000 ms).
Double flash The indication shows a series of two short flashes (200 ms each), punctuated by a brief off phase
(200 ms). The series ends with a long off phase (1000 ms).
Tab. 7.27: LED states
