9.3 PLC Control program sequence of the PMM
Start
Start & Status.Absorber
too hot == 1

Start & Status.PMM is
idle == 0
Start & Status.PMM is
idle == 1
Shutter.err == 1
Shutter.err == 1


Status.Measurement finished == 1
Finish


Status.Shutter is open == 1

Status.PMM is idle == 1

Status.Ready for measurement == 1

Status.Measurement running == 1
Preparation
Do Reset
Open Shutter
Do Start
Do Laser pulse
Wait Running
Close Shutter
Read Results
9.4 Internal conditions
PMM is idle
Ready for Measurement
Calculate Power
Command "Start
Measurement"
&
Statusbit Shutter is open == 1
Command
"do_reset"
Automatically
Statusbit Measurement finished == 1
Laser pulse
